KSB  |  gate valve  |  STAAL 100 AKDS  |  carbon steel

PCF Declaration available. Learn more
Select product configuration

Reset selection

DN

50
80
100
125
150
200
250
300

Pressure Nominal

63
100

Seal

metalic

Connection

Welded Ends

Valve Actuator

handwheel

Product Description

Specifications

Information & Downloads

Gate valve STAAL 100 AKDS by KSB made of carbon steel with welded ends according to DIN/EN. Forged or welded body with cover flange, non-rotating spindle, movable wedge plates for precise adaptation to the seat surfaces, sealing surfaces made of wear- and corrosion-resistant 17% chrome steel or stellite. Suitable for nominal diameters DN 50 to DN 600, nominal pressure PN 63 and PN 100, temperature range -10 °C to +530 °C. Versions available with handwheel, electric or pneumatic actuator. Increased external sealing safety thanks to comb-profiled cover gasket and chambered graphite packing. Standard back seal provides blow-out protection. Maintenance-friendly design with plate holder and bayonet connection (up to DN 250) or DIN/ISO mounting flange (from DN 300). Long service life due to armored sealing surfaces and ball-bearing threaded bushing. All information provided for technical reference only. Subject to change and correction.
STAAL 100 AKDS
gate valve
13CrMo4-5
carbon steel

You have questions about this product?

Please use our contact form, we will get back to you as soon as possible.

Important note: The information contained in this product description about the nature or usability of materials or products are not property warranties, but serve as a description. The information with which we wish to advise you is based on the manufacturer's experience and our own. We cannot guarantee the results of the processing and utilization of the products.

The product images shown here may differ from the original material due to production reasons. Colors and surfaces vary due to individual settings such as resolution and color/brightness settings of your display device.

Errors and omissions excepted.
