KSB | gate valve | STAAL 100 AKD | carbon steel

PCF Declaration available. Learn more

Select product configuration

Reset selection

DN

100

125

150

200

250

300

Pressure Nominal

100

Seal

metalic

Connection

Flanges

Valve Actuator

handwheel

Product Description

Specifications

Information & Downloads

Gate valve STAAL 100 AKD/AKDS by KSB made of carbon steel with flanges (AKD) or welded ends (AKDS) according to DIN/EN. Forged or welded body with cover flange, non-rotating spindle, movable wedge plates for precise adaptation to the seat surfaces, sealing surfaces made of wear- and corrosion-resistant 17% chrome steel or stellite. Suitable for nominal diameters DN 50 to DN 600, nominal pressure PN 63 and PN 100, temperature range -10 °C to +530 °C. Versions with handwheel, electric or pneumatic actuator. Increased sealing safety through comb-profiled cover gasket and chambered graphite packing. Standard back seal provides blow-out protection. Service-friendly design with movable wedge plates, bayonet connection (up to DN 250), or DIN/ISO flange (from DN 300). Long service life through armored sealing surfaces and ball-bearing threaded bushing. All information provided for technical reference only. Subject to change and correction.

Type name of part

STAAL 100 AKD

Valve type

gate valve

Alloy

1.0460

Material

carbon steel
