Superstructures

Find the right product for your needs

Discover our selection of safe and modern products. Do you have any questions or would you like personal advice? Our experts will be happy to advise you and develop the best solution with you. Feel free to use the contact option for your desired product.




Y-steel sleeper St 98

 Y-StahlschwelleSt98 Image
Material:S235JR
Rail shape:49E5 / 54E4 / 60E2
Deflection:600 mm / 650 mm
Length:2,300 mm
Threshold type:
  • Normal threshold (No)
  • Transition threshold left (Ttl)
  • Right Transition Threshold (Ttr)

Contact: angelika.kruk@thyssenkrupp-materials.com






Steel sleeper St 82 K

StahltrogschwelleSw82 Image
Material:S235JR
Rail shape:49E5 / 54E4 / 60E2
Length:2,400 mm / 2,600 mm
Insulation:
  • Without insulation
  • Single-sided insulation
  • Insulation on both sides

Contact: sonja.kuprat@thyssenkrupp-materials.com






Steel bridge sleeper

Stahlbruckenschwelle Image
Scope: Open truss bridge
Rail shape: 49E5 / 54E4 / 60E2
Length / Strap Type: Different beam types and lengths possible
Further information:
  • Alternatively with guide device
  • Individual adaptation of the construction to the requirements of the project / bridge

Contact: sonja.kuprat@thyssenkrupp-materials.com






ECF Rail Fastening System

ECF Image
Rail shape: 49E5 / 54E4 / 60E2
Underground: Steel / Concrete
Fortification:
  • Through-hole Cladding
  • Threaded welding Stud
  • Anchor Bolt
  • Threaded Rod
Rail Iron:
  • Tension Clamp / Clamp Plate
Type:
  • A-two-hole
  • B-four-hole
  • D-two-hole diagonal

Contact: sonja.kuprat@thyssenkrupp-materials.com






Command and Control Facility

Fuhrungseinrichtung Image
Rail shape: 49E5 / 54E4 / 60E2
Groove width: 180 mm
Guided tour type:
  • Support trestle tk / DENA Tk
  • Guide Mounting Plate
  • Guide Bracket

Contact: sonja.kuprat@thyssenkrupp-materials.com




More questions?

On our Website you will find more information about our products as well as a configurator.

If you have any further questions or need further products and solutions, please feel free to contact us. Send us your request and we will contact you as soon as possible.
